Digital Spectrophotometer 304 & 305

Digital Spectrophotometer 304 & 305
Digital Spectrophotometer 304 & 305
Send Inquiry
Product Code : Model 304 & 305
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Piece/Pieces
  • Price Range
  • 170000.00 - 300000.00 INR
Product Description

Digital Spectrophotometer 304 & 305

Digital Spectrophotometer – 304 & 305 are the most economical, reliable, rugged and accurate instrument for spectrophotometric analysis of any concentration. Digital Spectrophotometer – 304 & 305 operates at a wavelength range of 340 nm to 960 nm. The output is available on a 3 1/2 digit red seven segment LED display in terms of %Transmission (%T), Absorbance (Abs.), and Concentration (Conc.).

FEATURES
  • Range 340 To 960 nm
  • Wavelength Resolution 1 nm
  • Highly Stable & Accurate
  • Direct Concentration Facility
  • Dual Digital Display For Wavelength & Data
  • 10 mm & 50 mm Path Length (in Model - 304 only)

SPECIFICATIONS

Model 304 305
Range 340 - 960 nm
Resolution %T: 0.1, Abs: 0.001, Conc.: 1
Output %T: 0 - 100, Abs: 0 - 1.99, Conc.: 0 - 1999
Detector Silicon Photodiode
Light Source 6V, 10W, Tungsten Halogen Lamp
Monochromator 600 line/mm Holographic Grating
Sample
Holder
10 mm glass square cuvettes and provision
for 50 mm glass square cuvettes also available
10 mm glass square cuvettes
Spectral
Bandwidth
5 nm
Wavelength
Resolution
1 nm
Wavelength
Accuracy
+ 2.5 nm
Repeatability + 2 nm
Recorder
Output
Available
Display 3 1/2 Digit Bright Red LED Display
Operating
Temp. Range
5oC to 45oC
Power 230 V + 10% AC, 50Hz
Dimensions
(L x B x H)
475 x 285 x 130 mm (Approx.)
Weight 8.5 Kg (Approx.)
Accessories Glass Square Cuvettes of 10 mm path-length: A set of 2,
Operation Manual and Dust Cover

Note : Specifications are subject to change due to continuous improvements.
