Tablet Hardness Tester

Display

Graphic LCD(240 x 128 pixels)

Keyboard

Alpha-Numeric Function Keys

Hardness Range

5-500N (800N Option Available)

Hardness Accuracy

>1N

Diameter and Thickness Range

0.5 35mm

Diameter Accuracy

>+0.05mm

Measuring Units

Measurable Units

KP Resolution Accuracy

Yes (1/10 or 1/100 Settable)

Tolerance

Yes (Programmable Tolerances T1, t2, and Plausibility)

Force Rate

Constant (Linear) Force or Constant (Linear) Speed

Number of Tests for Statistics

Up to 100

Stored Methods

Up to 10

Calibration Procedure

Requires 10mm Reference Block and 10kg Reference Weight(Certified)

Calibration Technique

No Tilt (User Friendly)

Distance Validation

10mm Certified Block (For Thickness and Diameter

Load Cell Linearity

3-Point Linear Calibration with Certified Weight (5, 10, 15kg)

Load Cell Diagnostic Check

Yes (Check the Load Cell Signal Falls Within Range Before Making any Further Calibration)

Self Test

Yes

Fault Localization

Yes (Text Format)

Load Cell Overload Protection

Yes

Password Protection

Yes (For Advance Settings)

Factory Setting Reset

Yes

No Tablet Detection

Yes

Tracking Deletion

Yes

On Screen Statistic View

Yes

Interface Pots

USB Type A (2), USB Type B, LAN, RS-232(Serial Port for Balance Connection), Parallel Printer and 40 Column Thermal / Mini Dot Matrix Printer

Dimensions

22.4 (w) x 14.6(h) x 14.2(d) / (57 cm x 37 cm x x36 cm)

Weight

Without Printer: 15.4 lbs. / (7 kg)

With Printer: 17.6lbs./ (8 kg)

Electrical Power

115V + 15V, 50/60 Hz or 230V + 23V, 50/60 Hz
